RFID UHF Smart card

RFID Smart cards

Description

The UHF Smart card have the ability to be read at long ranges (up to 20+ feet away). Excellent credential for tracking important, high value assets, streamline your warehouse storage facilities and even help manage ski slope usage by tracking patrons and which slopes are being utilized most. Out of the box technology offers none encrypted features however you have the ability to load your own custom keys to encrypt and offer greater layers of security on top your cards and tags.
UHF can be integrated with other technologies within your badge like low frequency 125 kHz proximity cards and high frequency 13.56 MHz contact-less Hybrid Smart cards.

Applications:
  • Supply Chain Management
  • Asset Management
  • Factory Automation
  • Inventory Management

    • Technical Specifications

    Product Code RRUHFSM01
    Material PVC
    Colour White
    User Memory 512 bit
    Thickness 0.8 mm
    Size (in mm) 85mm X 54mm
    Operating Frequency 865-867 MHz
    Standard / Protocols ISO 18000-6C: EPC Class1 Gen2
    Temparature -15°C to +65°C
    Integrated Circuit Alien Higgs3

    Downloads

    Sr. No. Type Description Download Upload Date
    1
    2
    3
